INNOVATION
Customers can avail easy payments plan for :
ACE+ not only generates thousands of virtual frameset prototypes to satisfy Stiffness, Weight and Compliance targets, but now also includes a fourth key factor, Aerodynamics.
The superlight carbon cages seamlessly integrate with the reshaped down tube and seat tube, resulting in significant drag reduction when used with bottles. Available as an upgrade on the Teammachine SLR line.
The latest evolution of our signature D-Shape seatpost: this optimized design features the minimalist saddle clamp, resulting in lower weight; while still retaining excellent aerodynamic performance and compliance.
The new Teammachine SLR is more compliant than ever, thanks to the latest evolution of the Tuned Compliance Concept (TCC) technology. Fine tuning of the carbon layups, essential vertical frame and seatpost flex, to improve traction and control, resulting in reduced muscle fatigue.
Renowned for its power transfer, the new Teammachine SLR goes one step further, with its new down tube shape and optimised carbon layup providing even greater bottom bracket shell support.
An aerodynamically reshaped fork with stealth dropout design and integrated thru-axle nut show that high technical proficiency can go hand in hand with beautiful, minimalist aesthetics.
Frame
Teammachine SLR Carbon with Aerocore Design • Stealth Dropout Design • TCC Race Compliance Level • PF86 Bottom Bracket • Integrated Seatpost Clamp • Flat Mount Disc • 12x142mm Thru-Axle • Optimized for Aerocore Bottle Cages
Fork
Teammachine SLR Carbon • TCC Race Compliance Level • Internal Cable Routing • Flat Mount Disc • Stealth Dropout Design • 12x100mm Thru-Axle • 48mm Offset (Size 47-51), 43mm Offset (Size 54-61)
Chainwheel
SRAM RIVAL AXS 48-35T
Cassette
SRAM RIVAL XG-1250 10-36T
Chain
SRAM RIVAL 12 Speed
Rear Derailleur
SRAM RIVAL eTap AXS
Shifters
SRAM RIVAL eTap AXS HRD
Brakes
SRAM Rival eTap AXS HRD, Centerline X Rotors (160/160)
Handlebar
BMC RAB 02, Ergo Top Shape, Compact Bend
Stem
BMC RSM01
Seatpost
Teammachine SLR Carbon D-Shaped Seatpost • 15mm Offset
Saddle
Fizik Antares R7
Hubs
XRD-522
Rims
XRD-522, Tubeless Ready, 25 mm
Tires
Vittoria Rubino, 25mm
Tire Clearance
30mm (Measured Width)
Weight
8.50kg / 18.74lb
Weight Limit
110kg / 242lb
ASTM Classification
Level 1Size | 47 | 51 | 54 | 56 | 58 | 61 |
---|---|---|---|---|---|---|
Rider Height CM | <166 | 166-174 | 172-180 | 178-186 | 184-192 | >190 |
Stack MM | 506 | 530 | 550 | 565 | 584 | 608 |
Reach MM (reach) | 367 | 377 | 386 | 392 | 401 | 409 |
Seat Tube MM (st) | 423 | 468 | 504 | 524 | 545 | 574 |
Top Tube MM (tt) | 517 | 534 | 549 | 559 | 574 | 589 |
Head Tube MM (ht) | 110 | 130 | 145 | 165 | 184 | 210 |
Seat Tube Angle (sa) | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 |
Head Angle (ha) | 71.5 | 71.5 | 72.3 | 72.3 | 72.3 | 72.3 |
Rear Center MM (rc) | 410 | 410 | 410 | 410 | 410 | 410 |
Front Center MM (fc) | 568 | 586 | 589 | 599 | 614 | 630 |
Wheelbase MM (wb) | 968 | 986 | 989 | 1000 | 1015 | 1030 |
BB Drop MM (drop) | 69 | 69 | 69 | 69 | 69 | 69 |
Fork Length MM (fl) | 368 | 368 | 368 | 368 | 368 | 368 |
Fork Rake MM (fr) | 48 | 48 | 43 | 43 | 43 | 43 |
Trail MM (trail) | 63 | 63 | 63 | 63 | 63 | 63 |
Crank Length MM | 170 | 170 | 172.5 | 172.5 | 175 | 175 |
Stem Length MM | 90 | 90 | 100 | 110 | 110 | 120 |
Stem Angle | ±8 | ±8 | ±8 | ±8 | ±8 | ±8 |
Bar Width MM | 400 | 420 | 420 | 420 | 420 | 440 |
Bar Drop MM | 125 | 125 | 125 | 125 | 125 | 125 |
Bar Reach MM | 70 | 70 | 70 | 70 | 70 | 70 |
Post Offset MM | 15 | 15 | 15 | 15 | 15 | 15 |
Standover Height mm | 717 | 752 | 779 | 797 | 817 | 843 |
Seatpost Length MM | 330 | 380 | 380 | 380 | 380 | 380 |
